CMC Tubular Webbing
SKU: 200101
By CMC Rescue
Product Info
Mil-Spec Needle Loom Nylon Web
After thorough investigation, which included reviewing web construction, manufacturer's tests, and performing our own field evaluations, we feel the mil-spec needle loom web we now offer is comparable in strength and abrasion resistance to the previous-generation shuttle loom (spiral weave) web.
One-inch web is sold by the foot, with a maximum spool length of 300'. Two-inch web is sold by the 150' spool.
Note: Military standards allow for up to three sections per spool.
Specs
| Option | Item | Weight per Foot | Width | Color | MBS | Spool Length |
|---|---|---|---|---|---|---|
| Orange | 200101 | 0.5 oz (14 g) | 1 in (25 mm) | Orange | 4,000 lbf (17.8 kN) | 300 ft (91 m) |
| Blue | 200102 | 0.5 oz (14 g) | 1 in (25 mm) | Blue | 4,000 lbf (17.8 kN) | 300 ft (91 m) |
| Red | 200103 | 0.5 oz (14 g) | 1 in (25 mm) | Red | 4,000 lbf (17.8 kN) | 300 ft (91 m) |
| Black | 200105 | 0.5 oz (14 g) | 1 in (25 mm) | Black | 4,000 lbf (17.8 kN) | 300 ft (91 m) |
| Green | 200106 | 0.5 oz (14 g) | 1 in (25 mm) | Green | 4,000 lbf (17.8 kN) | 300 ft (91 m) |
| Yellow | 200107 | 0.5 oz (14 g) | 1 in (25 mm) | Yellow | 4,000 lbf (17.8 kN) | 300 ft (91 m) |
| OD Green | 200108 | 0.5 oz (14 g) | 1 in (25 mm) | O.D. Green | 4,000 lbf (17.8 kN) | 300 ft (91 m) |
| Red - 2 Inch | 200203 | 2 in (50 mm) | Red | 8,000 lbf (35.6 kN) | 150 ft (46 m) |
