CMC Helitack Airbag

SKU: 724247

Product Info

The Helitack AirBag is designed for rapid extraction of a subject by means of a single-point suspension from a helicopter by short-haul or hoist evacuation. Constructed from heavy-duty 1,000-denier Cordura nylon for long life and durability in harsh environments.

Key Features
  • Device can be used with/without backboard, rigid litter or vacuum body splint
  • Integrated machined aluminum Cobra Buckles are secure, easy to adjust, and expedite loading/unloading process
  • Bi-lateral patient access ports offer quick patient access during operation
  • Adjustable hood helps protect patient’s face
  • 2 steel D-ring attachment points
  • 2 internal straps with Cobra Buckles for securing top of backboard or litter
  • 3 color-coded internal patient packaging straps with quick-connect buckles
  • 10 hi-viz support handles aid in carrying, positioning and loading the subject
  • Full-length safety-glow accents reflect and glow for enhanced night visibility
  • 8 bridle straps offer adjustable lengths for ideal configuration to aircraft
  • 2 side stowage pockets for bridle when carrying on trails
  • Internal/external fabrics clean easily
  • Compact design uses minimal storage space: 21” L x 11” D
  • Quick-detachable storage bag included
  • Load limit: 2,500 lbf (11 kN)
  • UL Classified to NFPA 1983 – Litter
  • Made in USA
Specs
PRODUCT WEIGHT 14.5 LB (6.5 KG)
DIMENSIONS
21” L X 11” D (STORED IN BAG), 92” L X 30” W (OPENED FLAT)
COLOR RED/ GRAY/ BLACK
NFPA RATING LITTER
